Taico TK10200 - 4. Parameter Specifications; 4.1 Physical Dimensions; 4.2 Battery Electrical Parameters

6
4. Parameter Specifications
4.1 Dimensions
4.2 Battery Parameters
Project
Parameters
Model
TK10200 (51.2V200Ah)
Nominal voltage
51.2V
Nominal capacity
200Ah
Combination mode
16 Series
Dimensions W×D×H (mm)
482×500×280
Weight
About 84KG
Working voltage
43.2-58.4V
Charging voltage
56.8--58.4V
Charging current limiting
10A（The default charging current is greater
than 55A, and the current limiting is on）
Standard charging current current
20A（0.2C）
Maximum continuous charging current
50A（0.5C）
Standard discharge current
20A （0.2C）
Maximum continuous discharge current 100A （0.5C）
Charging temperature range
0~50°C
