C - 6 Diagnostics and fault finding 11/98 IPN: 449-51000-01
Table C-1: Test commands (continued)
Function Description CCTM code Parameters
Radio info Read radio serial number 94/131 Returns: 6 digit number (hex)
Read DSP software version number 132 Returns: 4 digit number (hex)
Read radio software version number 96 Returns: 4 digit number
Read radio type 130 Returns: radio type (P or M),
frequency band (B-J), channel
spacing (1 or 2)
Synth Load absolute synth frequency 101 tttttt T rrrrrr R F (see Table C-2)
Load synth reference divider 102 8 to 16383
Config Set volume pot 110 0 to 255
Set transistor gate bias 111 0 to 255
Set TCXO mod 112 0 to 255
Set VCO mod 113 0 to 255
Set Tx power level 114 0 to 255
Set TCXO coarse frequency 115 0 to 255
Set TCXO fine frequency 116 0 to 255
Set Rx front end tuning 117 0 to 255
Set squelch threshold 118 0 to 255
Set CTCSS modulation 120 0 to 32767
Set DCS modulation 121 0 to 32767
Set FFSK modulation 122 0 to 32767
Set Selcall modulation 123 0 to 32767
Set DTMF modulation 124 0 to 32767
Set voice modulation 125 0 to 32767
Force DCS signalling (023 tone) 126 None
Force CTCSS signalling (67.0 Hz) 127 None
Force Selcall signalling (2000 Hz
for 2 seconds)
128 None
Force DTMF signalling (tone A) 129 IN: 1 = start encoding,
0 = stop encoding
Read calibrated volume setting 136 Returns: 0 to 255
