D - 18 Servicing the radio 11/98 IPN: 449-51000-01
Table D-4: Orca Excel spares kit (TOPA-SP-103)
IPN Description
Quantity
supplied
Reference
345-00020-01 Chassis screw (M2*8 mm Pan Pozi) 10 D-1 (3)
311-01044-00 Channel selector knob 20 D-2 (1)
311-01043-00 Volume control knob 20 D-2 (2)
316-06633-00 Knob label 5 D-2 (3)
362-01092-01 Main seal 20 –
303-11194-02 Handportable chassis 5 D-4 (2), D-5 (3)
360-02015-00 Microphone grommet/seal 10 D-5 (1)
311-03099-00 PTT keypad 20 –
316-85124-00 PTT retaining plate 10 –
360-01060-00 PTT/function key actuator 40 –
312-01071-00 Lens 10 D-6 (1)
349-00030-00 Speaker screw (1.8*5 mm Torx) 10 D-7 (3)
252-00010-55 Speaker 0.5 W 16
Ω
5–
302-05231-01 Speaker mounting bracket 5 –
369-01039-00 Speaker adhesive ring 5 –
231-00010-45 Channel selector switch 10 D-8 (2), D-9 (2)
040-05500-07 Volume control switch 10 D-8 (3), D-9 (3)
232-00010-37 PTT tact switch 5 D-8 (8), D-9 (6)
345-00020-00 PA screw (M2*5 mm Pan Pozi) 10 D-8 (10)
252-00010-56 Microphone 5 D-8 (11)
356-01077-00 Battery contact probe 10 D-9 (7)
362-01087-00 Battery contact seal 10 D-9 (8)
308-01057-01 Aux dummy rear cover 20 –
220-01414-03 Aux flex connector PCB 10 D-10 (1)
362-01089-00 Auxiliary flex seal 10 D-10 (2)
362-01088-00 Rear panel seal 10 D-10 (5)
316-06632-01 Rear panel 5 D-10 (7)
219-50029-00 RF out assembly 5 D-11 (1)
240-02100-55 Antenna SMA connector 10 D-12 (4)
353-00010-42 Ribbed lock washer (M6*10*0.7 mm) 30 D-12 (7)
352-01053-00 Antenna SMA connector nut 10 D-12 (8)
352-00010-52 Channel/volume control nut (M6*7.9*3 mm) 20 D-12 (9)
362-01091-01 Knob seal 10 D-12 (10)
303-30071-01 Battery catch 20 –
303-50087-00 Belt clip 20 –
008-36671-70 LCD display 5 –
304-07041-02 LCD holder 5 –
311-03101-01 Orca Excel keypad 10 –
220-01501-00 User interface loom PCB 5 –
OPP200: Orca Excel front panel assembly. This comprises the follow-
ing parts:
1–
252-00010-55 Speaker 0.5 W 16
Ω
1
302-05231-01 Speaker mounting bracket 1
307-01021-00 Speaker grill 1
312-01071-00 Lens 1
316-06633-00 Knob label 1
316-06636-00 Orca Excel front panel 1
349-00030-00 Speaker screw (1.8*5 mm Torx) 2
354-01044-00 Bush M2 threaded brass 2
369-01039-00 Speaker adhesive ring 1
OPF201: Orca Excel user interface PCB and polyester dome, assem-
bled on the shield. This comprises the following parts:
5–
OPF200 User interface PCB assembly 5
311-04004-00 Polyester dome 5
319-01203-01 Shield 5
