M800-00 General A1.1
Copyright TEL 31/08/96
1 General
If further information is required about any ancillary equipment or this Manual, it may
be obtained from Tait Electronics Ltd or accredited agents. When requesting this infor-
mation, please quote the equipment type number (e.g. T807-10) and serial number. In
the case of the Service Manual quote the Tait Internal Part Number (IPN), e.g. M800-00-
100, and for circuit diagrams quote the 'Title', 'IPN' and 'Issue'.
1.1 Caution: CMOS Devices
This equipment contains CMOS Devices which are susceptible to damage from static
charges. Care when handling these devices is essential. For correct handling proce-
dures refer to the manufacturers' data books, e.g. Philips data books covering CMOS
devices, or Motorola CMOS data books, Section 5 'Handling', etc.
Figure 1.1 Typical Antistatic Bench Set Up
An antistatic bench kit (refer to Figure 1.1) is available from Tait Electronics Ltd under
the usual consumable goods ordering system. The kit is held in stock under IPN
937-00000-34 and contains:
• 1 conductive rubber bench mat
• 1 earth lead to connect the mat to ground (c/w 1M series resistor)
• 1 wrist strap
• information leaflet.
conductive rubber
bench mat
metal frame
to building earth
(not mains earth)
via 1M series resistor
conductive
wrist strap
