C1.14
T856/857 General Information
M850-00
31/09/98 Copyright TEL
1.4 T856 Standard Product Range
The following table lists the range of standard T856 types (i.e. no options fitted) availa-
ble at the time this manual was published. Consult your nearest Tait Dealer or Cus-
tomer Service Organisation for more information.
Caution:
T856-16-XXXX Product Types
In the United States the 406 to 406.1MHz frequency range is reserved
for use by Distress Beacons.
Do not program transmitters to operate in
this frequency range in the United States.
You can identify the transmitter type by checking the product code printed on a label on
the rear of the chassis (Figure 1.1 in Part A shows typical labels). You can further verify
the transmitter type by checking the placement of an SMD resistor in the table that is
screen printed onto the PCB (refer to Section 6.1 for more details).
Frequency Range (MHz) 400-440
Deviation (kHz) 2.5 2.5 4 5
TCXO ±1ppm -20°C to +60°C
••••
Transmitter Type: T856- 16-0000
a
a. United States market only.
15-0000 13-0000 10-0000
Frequency Range (MHz) 440-480
Deviation (kHz) 2.5 2.5 4 5
TCXO ±1ppm -20°C to +60°C
••••
Transmitter Type: T856- 26-0000
a
25-0000 23-0000 20-0000
Frequency Range (MHz) 480-512 480-520
Deviation 2.5 2.5 5
TXCO ±1ppm -20° to +60°C
•••
Transmitter Type: T856- 36-0000
a
35-0000 30-0000
