IPN 220-01398-02
C6.3.8
T857 PCB Information
M850-00
31/09/98 Copyright TEL
IPN Legend Description IPN Legend Description
T857 Mechanical & Miscellaneous Parts (220-01398-02)
070-01001-00 13/25 D-RANGE 15 WAY COMPL T800
070-02001-00 LED RED COMPL T800 RX/TX/EX
070-02002-00 LED GREEN COMPL T800 RX/TX/EX
206-00010-11 COAX 50 OHM RG316-U PTFE
Connects SK310 to SK420.
220-01145-02 1 PCB T85X VCO
220-01398-02 2 PCB T857 SERIES II TOP
232-00020-26 3 BUTTON 232-00010-26 SWITCH
240-00100-43 PLG COAX MINI PIN CRIMP 1.5D
For coax connecting SK310 to SK420.
240-02100-06 4 SKT COAX N TYPE PNL MTG OP-TER
240-04020-62 SKT 2 W RECEP SHORTING LINK
PL205/210/215/220.
303-11169-03 5 CHASSIS PAINTED T800 SERIES
303-23118-00 6 COVER A3M2247 D RANGE T855/7
303-50074-00 7 CLIP A3M2246 SPRING CLAMP T857
303-50078-00 8 CLIP A4M2630 SPR. CABLE CLAMP
308-01007-01 9 HANDLE BASE STATION SERIES II
312-01052-01 10 LID TOP PNTD A1M2364 T800
312-01053-01 11 LID BOTTOM PNTD A1M2364 T800
316-06619-00 12 PNL FRT EX, NO EX OUT SER II
345-00040-10 14 SCRW M3X6MM P/POZ ST BZ
349-00020-36 15 LIM)SCREW TT M3X8m PANTORX BLK
349-00020-43 16 SCRW T/T M4X12MM P/POZ BZ
349-00020-45 17 SCRW T/T M4X20MM P/POZ BZ
350-00016-42 18 SPACER 5MM HI 8MM ST 2.5MM HO
352-00010-08 19 NUT M3 COLD FORM HEX ST BZ
352-00010-29 20 NUT M4 NYLOC HEX
353-00010-10 21 WSHR M3 FLAT 7MMX0.6MM ST BZ
353-00010-13 22 WSHR M3 S/PROOF INT BZ
362-00010-23 23 GASKET SIL TO-220 CLIP MTG.
362-00010-33 24 GROMMET LED MTG 3MM
365-00011-53 LABEL 104X37MM
365-00100-20 LABEL WHITE S/A 28X11MM
365-01541-00 LABEL TX/RX/EX TYPE APR/SER NO
399-00010-51 BAG PLASTIC 75X100MM
410-01081-01 CRT T800 SERIES II
410-01082-01 CRTN 10 T800 KIWI 423X410X360
