TB8100 Installation Guide Connection 31
© Tait Electronics Limited February 2007
the rear of the PA. Connect the other end to the auxiliary DC input
connector
d at the rear of the reciter.
Note If you are using an older reciter with a 4-way connector, you will
need to use Method 2.
2. On the D-range plug that is fitted to the system interface connector
e on the reciter, link digital out 1 to +AUX_V.
Method 2 1. Connect one end of the Power Saving control cable b to the Power
Saving control connector
c at the rear of the PA.
2. Cut the socket off the other end of the cable. Connect the wires
directly to the D-range plug fitted to the system interface connector
e as follows:
■ red - digital out 1
■ black - ground.
The pin allocations for the Power Saving control connector on the PA are
given in the following table.
If you wish to make up your own cable, use the following connector for
both the PA and reciter connections:
■ 2x1-way Molex 43025-0200/crimp socket 43030-0001 female.
Pin Signal Name Signal Type Notes
1 PA shutdown input active low
2 ground ground
external view
12
