50 TA2922 Universal Line Interface Service Manual
© Tait Electronics Limited March 2010
C40 018-14100-00 CAP 1n 50V ±10% 0603 X7R C1 1J13
C41 018-14100-00 CAP 1n 50V ±10% 0603 X7R C1 1H13
C42 018-14100-00 CAP 1n 50V ±10% 0603 X7R D1 1J14
C43 018-14100-00 CAP 1n 50V ±10% 0603 X7R C1 1J14
C44 018-14100-00 CAP 1n 50V ±10% 0603 X7R C1 1J14
C45 018-14100-00 CAP 1n 50V ±10% 0603 X7R C1 1H14
C46 015-26330-08 CAPCer 330n 10V 5% 0805 X7R A3 1G3
C47 018-12220-10 CAP 22p 50V NPO ±1% 0603 C8 1B4
C48 018-12220-10 CAP 22p 50V NPO ±1% 0603 C8 1B4
C49 016-08100-03 CAP eltro 10uF 35V 105° 2000h B7 1K10
C50 018-16100-10 CAP 100n 50V 10% 0603 X7R B6 1J10
C51 015-27100-08 CAPCer 1uF 16V 10% 0805 X7R A7 1K11
C52 018-16100-10 CAP 100n 50V 10% 0603 X7R B8 1E6
C53 018-13100-00 CAP 100p 50V NPO ±5% 0603 E3 1D8
C54 018-14100-00 CAP 1n 50V ±10% 0603 X7R A7 1E3
C55 018-14100-00 CAP 1n 50V ±10% 0603 X7R F1 1F10
C56 016-08100-03 CAP eltro 10uF 35V 105° 2000h E1 1F10
C57 018-14100-00 CAP 1n 50V ±10% 0603 X7R E1 1F11
D1 001-10000-99 DIODE BAV99Dual sw SOT23 F3 1E8 1F8
D2 001-10335-00 DIODE Array 3V3 ESD ptctn SC88 D7 1D2 1D1
D3 001-10084-51 DIODE BZX84C5V1 Zen SOT23 G5 1J10
D4 001-10084-51 DIODE BZX84C5V1 Zen SOT23 G5 1J10
D5 001-10084-51 DIODE BZX84C5V1 Zen SOT23 E6 1G10
D6 001-10084-51 DIODE BZX84C5V1 Zen SOT23 F6 1G10
D7 001-10000-99 DIODE BAV99Dual sw SOT23 C10 1F7
D8 001-10000-99 DIODE BAV99Dual sw SOT23 D10 1F5
D9 008-10004-00 LED 0603 grn KGKTUltrabright C8 1E5
D10 001-10000-99 DIODE BAV99Dual sw SOT23 G3 1D10
D11 001-10000-99 DIODE BAV99Dual sw SOT23 G3 1D10
D12 001-10000-99 DIODE BAV99Dual sw SOT23 D8 1F3
DS1 002-10181-00 IC HCPL181 OPTO Fpak SO4 F3 1D9
F1 265-10055-00 FUSE 0.3A Reset SMD030-2 B2 1J2
FL1 059-16220-00 IND 0603CS 220nH 5% G5 1J9
FL2 059-16220-00 IND 0603CS 220nH 5% G5 1H9
FL3 059-16220-00 IND 0603CS 220nH 5% F6 1G9
FL4 059-16220-00 IND 0603CS 220nH 5% E6 1G9
Q1 000-10008-17 XSTR SMD BC817-25 NPN SOT23 E9 1H6
Q2 000-10008-17 XSTR SMD BC817-25 NPN SOT23 A8 1B10
Q3 000-10008-17 XSTR SMD BC817-25 NPN SOT23 F3 1E8
Q4 000-10008-57 XSTR SMD BC857 PNP SOT23 D8 1C9
Q5 000-10008-57 XSTR SMD BC857 PNP SOT23 E3 1D8
Q6 000-10008-17 XSTR SMD BC817-25 NPN SOT23 B8 1J4
Q7 000-10008-17 XSTR SMD BC817-25 NPN SOT23 B8 1J5
Q8 000-10008-17 XSTR SMD BC817-25 NPN SOT23 C9 1F7
R1 038-15100-10 RES 0603 10k 1% 1/10W D10 1H4
R2 038-15100-10 RES 0603 10k 1% 1/10W G8 1G6
R3 038-16105-10 RES 0603 105k 1% 1/10W C10 1F5
R4 038-15270-00 RES 0603 27k 5% 1/10W D9 1H5
R5 038-14470-10 RES 0603 4k7 1% 1/10W D9 1G5
Ref IPN Description PCB Schem
