TA2922 Universal Line Interface Service Manual 51
© Tait Electronics Limited March 2010
R6 038-15100-10 RES 0603 10k 1% 1/10W G8 1G7
R7 038-15100-10 RES 0603 10k 1% 1/10W D9 1G7
R8 038-15100-10 RES 0603 10k 1% 1/10W E3 1D8
R9 038-15100-10 RES 0603 10k 1% 1/10W A8 1B9
R11 038-15100-10 RES 0603 10k 1% 1/10W A7 1E3
R12 038-15100-10 RES 0603 10k 1% 1/10W D8 1C8
R13 038-15100-10 RES 0603 10k 1% 1/10W E3 1D8
R14 038-15100-10 RES 0603 10k 1% 1/10W D8 1C9
R15 038-15100-10 RES 0603 10k 1% 1/10W F3 1E8
R16 038-15100-10 RES 0603 10k 1% 1/10W E8 1C9
R17 038-15100-10 RES 0603 10k 1% 1/10W D8 1F3
R18 038-16100-10 RES 0603 100k 1% 1/10W D6 1D1
R19 038-16100-10 RES 0603 100k 1% 1/10W D6 1E1
R20 038-15220-10 RES 0603 22k 1% 1/10W E8 1H6
R21 038-15220-10 RES 0603 22k 1% 1/10W E9 1H7
R22 038-16100-10 RES 0603 100k 1% 1/10W D6 1D1
R23 038-16100-10 RES 0603 100k 1% 1/10W D6 1E1
R24 038-15100-10 RES 0603 10k 1% 1/10W F7 1J6
R25 038-15220-10 RES 0603 22k 1% 1/10W E9 1J7
R26 038-16180-00 RES 0603 180k 5% 1/10W F9 1J7
R27 038-16120-10 RES 0603 120k 1% 1/10W D9 1H8
R28 038-16100-10 RES 0603 100k 1% 1/10W D9 1H8
R29 038-16100-10 RES 0603 100k 1% 1/10W E9 1G9
R30 038-17100-10 RES 0603 1M 1% 1/10W C10 1F6
R31 038-16100-10 RES 0603 100k 1% 1/10W D9 1G8
R32 038-16100-10 RES 0603 100k 1% 1/10W D9 1G8
R33 038-13560-10 RES 0603 560R 1% 1/10W F6 1J8
R34 038-13560-10 RES 0603 560R 1% 1/10W D9 1G8
R35 038-13100-10 RES 0603 100R 1% 1/10W F9 1H9
R36 038-16100-10 RES 0603 100k 1% 1/10W D6 1D1
R37 038-15120-10 RES 0603 12k 1% 1/10W D10 1H4
R38 038-14100-10 RES 0603 1k0 1% 1/10W E10 1H3
R39 038-15100-10 RES 0603 10k 1% 1/10W C10 1F5
R40 038-15120-10 RES 0603 12k 1% 1/10W B10 1J4
R41 038-14100-10 RES 0603 1k0 1% 1/10W B10 1J3
R43 038-17100-10 RES 0603 1M 1% 1/10W C8 1B4
R44 038-15100-10 RES 0603 10k 1% 1/10W C10 1F6
R45 038-15100-10 RES 0603 10k 1% 1/10W F3 1D8
R47 038-13470-00 RES 0603 470R 5% 1/10W D7 1F12
R48 038-13470-00 RES 0603 470R 5% 1/10W D7 1F12
R49 038-13470-00 RES 0603 470R 5% 1/10W D7 1F12
R50 038-13470-00 RES 0603 470R 5% 1/10W D6 1F12
R51 038-13470-00 RES 0603 470R 5% 1/10W D6 1F12
R56 038-14470-10 RES 0603 4k7 1% 1/10W G3 1D9
R57 036-05100-01 RES 1206 10k 5% G3 1D10
R58 036-05100-01 RES 1206 10k 5% G3 1D10
R59 038-15100-10 RES 0603 10k 1% 1/10W F8 1J6
R60 038-14240-10 RES 0603 2K4 1% 1/10W D8 1F3
R61 036-02100-03 RES 1218 10R 5% 1W B5 1K8
R63 038-14100-10 RES 0603 1k0 1% 1/10W A7 1K11
R64 038-16100-10 RES 0603 100k 1% 1/10W B8 1E5
R66 038-15100-10 RES 0603 10k 1% 1/10W B8 1J4
R67 038-15100-10 RES 0603 10k 1% 1/10W B8 1J4
R68 038-15100-10 RES 0603 10k 1% 1/10W C9 1F7
R69 038-13470-00 RES 0603 470R 5% 1/10W C8 1E5
Ref IPN Description PCB Schem
