10 Calibration basics TM8100 Mobile Radio Calibration Application User’s Manual
August 2004 © Tait Electronics Limited
■ Instruction boxes
■ Radio Model toolbar.
Sliders
Sliders typically modify a DAC setting in the radio. A slider appears as a line
with a movable button, and two arrow buttons either side. Moving the
button will alter a value in a box to the right of the slider.
To adjust a slider
■ Keyboard: select a slider using the Tab key. Press the left and right arrow
keys to adjust the value in the box in steps of 1, or the Page Up and Page
Down keys to adjust the value in steps of 10. To move the slider above
the upper safe limit of a field, hold shift and the right arrow key. The box
will turn red.
■ Mouse: select a slider by clicking on it. Click the < and > buttons to
adjust the value in the box in steps of 1, click on the line either side of
the movable button to adjust the value in steps of 10, or click and drag
the movable button. To move the slider above the upper safe limit of a
field, hold shift and click the > button. The box will turn red.
Important The purpose of the upper safe limit is to protect the radio
from component damage. Only move sliders over this limit
if you are certain that it is necessary for the radio being cal-
ibrated.
Option buttons
Option buttons are round buttons used to select one of a group of mutually
exclusive options. They are typically used to select a current state.
To change data in a group of option buttons:
■ Keyboard: select an option button using the Tab key. Select the radio
button by pressing the Space bar.
■ Mouse: select an option button by clicking on it.
Instruction boxes
An instruction box contains text that describes the steps for a calibration
task. After completing each step, select or click the Next> button to move
to the next step.
Radio Model toolbar
When you read a radio, the type of radio will be displayed on the radio
model toolbar. There are currently three types of radio available for
calibration, Standard, Trigger Base, and Mid Power.
The following are the main differences between the radio models:
