252 Transmitter Fault Finding (50W/40W Radios) TM9100 Service Manual
© Tait Electronics Limited August 2005
Figure 11.4 Point for measuring the power supply to the PA driver (B1 band)
B1 BAND
L306
Q308
R339
R350
Q306
PAD TOP
MEASUREMENT
POINT ON L306
POINT 1 ON R350
MEASUREMENT
POINT ON R339
POINT 2 ON R350
