TM9100 Service Manual Transmitter Fault Finding (25W Radios) 365
© Tait Electronics Limited August 2005
Figure 12.18 Circuitry under the
PIN TOP can, and points for attaching the test lead and test capacitor
B1 band H5/H6 bands
Mounting point
for test capacitor
Test padTest pad
