To trim thread
87
Chapter 5
1
2
3
4
5
6
7
8
9
10
11
VN03
2-7. To change thread trim timing (ATH Start Timing)
This function is for the purpose to improve thread trimming by changing moving timing of the thread trimming
knife.
2-7-1. Explanation on the screen
2-7-2. How to operate
The following is an example of setting ATH start timing to "+5"
(1) Set to main screen.
(2) Press F2 key while pressing SET key.
(3) Press F2 key.
(4) To select ATH drive start timing
Timing to start moving thread trimming
knife (Value is of main shaft angle)
This machine was shipped after being set to optimum values. To change these values,
consult the distributor. Some operating condition could cause occurrence of fault in thread
trimming.
To Next Page
