To adjust finishing of embroidering
112
Chapter 5
UO04
7-3. To divide a long stitch (Auto Jump)
This function makes the frame movement to divide by jump automatically when a stitch length exceeds a
setting value. This function reduces the load generated at the frame drive due to heavy weight of the material
to be embroidered. However, dividing by jump will reduce embroidering efficiency.
7-3-1. Explanation on the screen
7-3-2. How to operate
The following is an example that stitch length to jump automatically is set to "6.0".
(1) To open screen
(2) To select stitch length to perform automatic jump
2 Auto Jump
F1
4.0
240
240 360
[ ]
NO/2.0
[mm]
9.9
NO Yes/No
Frame Start Timing
Keep up R.P.M.
Setting for auto jump
NO: Not to perform
2.0 to 9.9:
The machine will jump automatically when a stitch
exceeding a set value is given. When a value is
4.0, the machine will jump automatically if stitches
of 4.1 mm and more are given. When the setting of
frame type is set to "Auto Clamp Frame", setting
range is 2.0 to 5.0 mm.
R.P.M. at auto jump
YES: To keep (remaining in high speed)
NO: Not to keep (speed reduction according to a stitch length)
Timing to start moving the frame (p.118)
To Next Page
