Various functions
146
Chapter 5
11-2. To color in every needle bar (Needle Bar Color)
Matching needle bar color with thread color used actually will display an image similar to the embroidered
product.
11-2-1. Explanation on the screen
11-2-2. How to operate
The following is the example of setting the needle bar No.1 to "red".
(1) To open screen
(2) To select the needle bar No.
(3) To select color
(4) To decide
10 Needle Bar Color
B
Pallet 32 colors
Cursor (selected color)
Needle bar No.
Needle bar color
10 Needle Bar Color
1
Are you ready ?
UO12
