Various functions
150
Chapter 5
11-6. To release fixing of main shaft motor (Main shaft brake)
It is the setting to release the fixing of the main shaft motor temporarily while the main shaft stops. This
function is used for the maintenance of the machine mainly.
11-6-1. Explanation on the screen
[a] Fixing of main shaft motor
YES: To fix the main shaft motor while the main shaft stops (usual setting)
NO: Not to fix the main shaft motor while the main shaft stops
Even if "NO" is selected, it will be switched to "YES" after starting the machine.
[b] Current main shaft angle
11-6-2. How to operate
The following is an example that the main shaft motor is set to "not to fix".
(1) Set to main screen.
(2) Press F3 key while pressing SET key, and press SET key further.
(3) To select not to fix
F3
2 Main shaft brake
SET
YES
100
YES / NO
[]
[a]
[b]
SQ10
