TAJIMA TMBR-SC - Page 173

To return the frame (Frame Back) / to advance the frame (Frame Forward)
157
Chapter 6
1
2
3
4
5
6
7
8
9
10
11
UO04
1-2. To execute by Stop code, to specify number of stitches to execute
1-2-1. Explanation on the screen
[a] To perform Frame Back or Frame Forward in Stop code
: Not to execute
: To execute
[b] To perform frame back or frame forward by specifying the number of stitches
NO: Not to perform
1 to end stitch:
To perform (to perform Frame Back or Frame Forward for the number of stitches)
1-2-2. How to operate
The following is an example of executing frame forward by Stop code.
(1) To open screen
When performing this operation, do not put your hands, etc. on the table. Moving the
frame could injure you.
3 Frame Back/Frame Forward
C
FB
NO
1
39628
FB/FF
Stop code
Stitches
FB/FF Stitch Unit
Stitch Counter
1/3/5
[a]
[b]
CAUTION
!
3 Frame Back/Frame Forward
