To return the frame (Frame Back) / to advance the frame (Frame Forward)
162
Chapter 6
UO04
1-5. To change a frame feed amount of frame back / frame forward
Set the frame feed amount when Frame Back/Forward by the stop switch is performed for 11 or more
stitches continuously.
1-5-1. Explanation on the screen
1-5-2. How to operate
The following is an example of setting the frame feed amount to "5".
(1) To open screen
(2) To move the cursor to "FB/FF Stitch unit"
(3) To select frame feed amount
3 Frame Back/Frame Forward
C
FB
NO
1
39628
FB/FF
Stop code
Stitches
FB/FF Stitch Unit
Stitch Counter
1/3/5
Frame feed amount
1: Feed the frame by 1-stitch unit.
3: Feed the frame by 3-stitches unit.
5: Feed the frame by 5 stitches unit.
3 Frame Back/Frame Forward
To Next Page
