Message display
26
Chapter 3
UO04
2. Message display
2-1. Condition data
When registering the design (saving format is T3, or T2 design) saved in the USB memory into the machine
memory
, the following message will appear.
There are following three items of condition data (file) except the one described above. By setting them after
data set, each setting contents will be added in a design. Therefore, it is unnecessary to perform setting
again when you embroider this design next time.
(1) Scaling up/down/reversion of design
(2) Design repetition
(3) Automatic Offset
2-1-1. When reading the design (Example: TAJIMA_W) saved in the USB memory by a personal computer
Indications in a personal computer are different as shown in the chart below depending on the saving form
at
(
T3, T2, T) of the design.
[About T2]
One design consists of three types of file (TAJIMA_W.CT0, TAJIMA_W.DGF, TAJIMA_W.TBF).
Saving format
Indication in personal
computer
Use
T3 TAJIMA_W.TCF Data integrating CT0, DGF and TBF of T2
T2
TAJIMA_W.CT0 Color change sequence, design start point
TAJIMA_W.DGF Size-reduced design (Thumbnail)
TAJIMA_W.TBF Stitch data of TAJIMA binary format
T TAJIMA_W.DST Stitch data of TAJIMA ternary format
Condition data (file) means the following two items in this case.
(1) Color change sequence
The whole color change sequence included in the desig
n
ca
n be registered into the machine memory. Therefore,
it
is un
necessary to set it again.
(2) Start point of design
The frame position where the machine star
ted
emb
roidering last time can be registered in the machin
e
m
emory. Therefore, it is unnecessary to adjust th
e
p
osition of the frame.
"YES">>SET
"NO">>E
Read Condition File?
To Next Page
