149
TROUBLESHOOTING
If a W
arning Lamp Flashes
W
arning lamp
Lamp name
Procedure
W
ater
separator
warning lamp
W
ater has accumulated in the water separator
. Drain
the water
.
Refer to page 133 “Draining the W
ater Separator”.
Fuel level
warning lamp
The fuel level is low
. Supply fuel.
Refer to page 42 “Fuel Filler Cap”.
L3J006
L3J005
