159
SPECIFICATIONS
Units: mm (inches)
Machine Dimensions
*:Telescopic arm fully retracted.
** : When equipped with Roof guard.
Mono-Boom
A 6555 (258.1) ← 6590 (259.4) ←←
B 2245 (88.4) ←←←←
C
2570 (101.2) / 2615 (103)**
2565 (101) / 2610 (102.8)**
2570 (101.2) / 2615 (103)**
←←
D 1720 (67.8) ←←←←
E 785 (30.9) 760 (29.9) 785 (30.9) ←←
F 2210 (87) 2180 (85.8) 2210 (87) ←←
G 2855 (112.4) 2830 (111.3) 2855 (112.4) ←←
H 2150 (84.6) ←←←←
J 450 (17.7) ←←←←
K 385 (15.1) 360 (14.2) 385 (15.1) ←←
L 2180 (85.8) ← 2285 (90.0) 2430 (95.7) 2320 (91.3)
M 1635 (64.3) ← 1745 (68.7) 1870 (73.6) 1735 (68.3)
N 2060 (81) ← 2170 (85.5) 2310 (91) 2180 (85.9)
P 695 (27.3) ←←←←
Q 735 (28.9) ←←←←
R 2150 (84.6) ←←←←
S 500 (19.7) ←←←←
T 4840 (190.6) 4845 (190.7) 4875 (191.9) 4975 (195.9) 4925 (193.9)
U 2000 (78.7) 1995 (78.6) 2000 (78.7) ←←
V80° ←←←←
W50° ←←←←
Standard Arm Middle Arm Long Arm
Telescopic Arm*
Rubber Crawlers Steel Crawlers Rubber Crawlers
Rubber Crawlers Rubber Crawlers
