163
SPECIFICATIONS
Operating Range
Units: mm (inches)
Units: mm (inches)
Mono-Boom
Mono-Boom
Middle Arm Telescopic Arm
Rubber Crawlers
––
Arm Fully Retracted Arm Fully Extended
Item
A Max. digging radius 7225 (284.4) 7065 (278.1) 8125 (319.8)
B Max. ground digging radius 7080 (278.7) 6915 (272.2) 7995 (314.8)
C Max. digging depth 4420 (173.9) 4245 (167) 5445 (214.4)
D Max. vertical digging depth 3655 (143.9) 3155 (124.3) 4365 (171.9)
E Max. digging height 7160 (281.9) 7025 (276.5) 7715 (303.8)
F Max. dumping height 5125 (201.9) 5005 (197.1) 5695 (224.3)
G Min. dumping height 1775 (69.1) 1935 (76.2) ––
H Max. vertical digging radius 4655 (183.3) 5075 (199.8) 5235 (206.1)
J Max. raising height 525 (20.7) ←←
K Max. lowering depth 410 (16.1) ←←
Item
Standard Arm Long Arm
Rubber Crawlers
Steel Crawlers
Rubber Crawlers
Steel Crawlers
A Max. digging radius 7055 (277.7) ← 7385 (290.8) ←
B Max. ground digging radius 6905 (271.8) 6910 (272) 7245 (285.2) 7250 (285.4)
C Max. digging depth 4240 (166.9) 4260 (167.8) 4590 (180.6) 4610 (181.5)
D Max. vertical digging depth 3475 (136.9) 3500 (137.8) 3830 (150.8) 3855 (151.8)
E Max. digging height 7025 (276.7) 7005 (275.7) 7290 (287) 7270(286.2)
F Max. dumping height 4995 (196.6) 4970 (195.6) 5255 (206.9) 5230 (205.9)
G Min. dumping height 1935 (76.3) 1915 (75.3) 1630 (64.3) 1610 (63.4)
H Max. vertical digging radius 4630 (182.3) ← 4700 (185) ←
J Max. raising height 525 (20.7) 505 (19.8) 525 (20.7) 505 (19.8)
K Max. lowering depth 410 (16.1) 435 (17) 410 (16.1) 435 (17)
