Takeuchi TB175 User Manual

165
SPECIFICATIONS
Operating Range
2-Piece Boom
Units: mm (inches)
A Max. digging radius 7650 (301.2)
B Max. ground digging radius 7510 (295.7)
C Max. digging depth 4440 (174.8)
D Max. vertical digging depth 3955 (155.7)
E Max. digging height 7970 (313.8)
F Max. dumping height 6000 (236.2)
G Min. dumping height 2310 (90.9)
H Max. vertical digging radius 4360 (171.6)
J Max. raising height 525 (20.7)
K Max. lowering depth 410 (16.1)
