6
Speaker
Copyright 2017 www.35rctank.com Page 4
4
Sprocket and wheels
do not insert polycap
remove
A10
for smooth wheel rotation,
enlarge hole with 4.2 drill
4.2
5
Turrret ring gear
turret ring gear
Attach B9 temporary
for alignment
Turret ring gear
upper hull
B9
B9
remove
1mm PS partition plate
For smooth turret rotation, remove
sharp edges with abrasive paper
