7
Connecting upper and lower hull
Copyright 2017 www.35rctank.com Page 5
16
5
5
5
13
1mm PS plate
1mm PS plate
X4
X4
attach to lower hull
8
Main gun
remove
alignment mark
metal barrel
Drill 2.5mm through hole
enlarge hole for recoil spring
