8
Main gun
Copyright 2017 www.35rctank.com Page 6
C15
turret servo assembly
recoil spring
insert barrel and secure set screw
9
Turret servos
Drill 4.5mm screw holes
M2x5
attach to upper turret
10
Main gun LED
press fit here, do not apply adhesive
LED expose during recoil
