WHAT IS WHAT
Since this manual covers several models, there may
be some diff erence between pictures and your unit.
Use the instructions that apply to your unit.
1. Fuel cap
2. Throttle trigger
3. Starter handle
4. Cutting attachment guard
5. Cutting attachment
6. Drive shaft tube
7. Handle
8. Ignition switch
9. Spark plug
10. Priming pump
11. Throttle trigger lockout
12. Choke lever
13. Engine
14. Gear case
15. Combi box spanner
16. Handling instructions
17. Goggles
18. Hex bar wrench
19. Top cover
