Tannoy ellipse

4
Fig. 1.
IEC input module showing voltage setting viewing window with
rating set at 100V - 120V.
Fig. 2.
IEC input module showing fuse location and input voltage selector
orientated for insertion at 100V - 120V usage.
Fig. 3.
IEC input module showing fuse location and input voltage selector
orientated for insertion at 200V - 240V usage.
