8.3: AMPLIFIER
A fuse is located just under the mains input (location 2 fig 1). Replacement is simple and a spare fuse is provided inside the
fuse housing itself. Always use the correctly rated fuse, as indicated on the silk screen-printing. Only qualified and authorised
personnel should undertake any other servicing regarding the amplifier section.
In case of any malfunction of the unit, the first thing to check should be the input connection, more especially if the source has
unbalanced outputs (see "Connecting your speakers" section) as improper connection can result in significant level reduction
and affect the response.
8.2: DRIVER REMOVAL
Remove the two port tubes from the front baffle panel. Remove the silver trim plate by hooking your fingers into the holes left
by the port tubes and carefully pulling the trim panel towards you. This will disengage the studs that hold the panel in place
and allow you to remove it to gain access to the driver itself. Undo the four chassis mounting screws and remove the driver, note
the polarity of the internal connections and disconnect the internal wiring. Take care not to damage the moving parts of the LF
driver.
To refit the driver, connect the cables from the crossover to the chassis terminals. Fit the driver into the mounting hole, making
sure that the internal connecting cables are not trapped or able to touch the LF cone. Fasten the screws finger tight and then
progressively tighten them down with the appropriate driver.
8.0: SERVICING 8.1: CABINET FINISH
To remove marks and scuffs use a soft brush. If necessary, a little warm water and detergent can be used but under no circumstances
use a solvent or abrasive cleaner.
7.0: WARRANTY
No maintenance of the Ellipse Monitor is necessary.
All components are guaranteed for a period of one year from the date of manufacture, subject to the absence of, or evidence
of, misuse, overload or accidental damage.
For further information please contact your dealer or the distributor in your country.
If you cannot locate your distributor please contact:
Customer Services, Tannoy Ltd, Coatbridge, Strathclyde ML5 4TF
T: +44 (0) 1236 420199 F: +44 (0) 1236 428230 www.tannoy.com
DO NOT SHIP ANY PRODUCT TO TANNOY WITHOUT PREVIOUS AUTHORISATION
This warranty in no way affects your statutory rights.
