Tannoy i5 AW User Manual

NOTE: The installation of this product must be
carried out in conformity with local building
standards. If necessary consult your local safety
standards officer before installing any product.
Alternatively, check any laws or bylaws. Tannoy
will not be held responsible for any damages
caused by the improper installation of any
bracket or loudspeaker.
9. Hardware
The i5 AW can be wall or ceiling mounted using the MB5Y bracket (Figure 1) or the
MB5B (Figure 3). Both are designed to offer maximum flexibility in selecting the
desired angles. Methods of mounting have been demonstrated in figures 2 & 3.
For this product to conform to weatherproof specification IP33CS in EN60529 it
should be mounted facing downwards at an angle greater than 35° from the vertical
(Figure 3)
Figure 1
Figure 2
Figure 3

Tannoy i5 AW Specifications

General

Brand	Tannoy
Model	i5 AW
Category	Speakers
Language	English
