Revolution Signature DC4 Revolution Signature DC4 T Revolution Signature DC4LCR
PERFORMANCE
Recommended amplifier power 20 – 100 20 – 125 20 – 125
(Watts RMS)
Continuous power handling 50 62 62
(Watts Peak RMS)
Peak power handling (Watts) 200 250 250
Sensitivity (2.83 Volts @ 1m) 87dB 87dB 87dB
Nominal Impedance (Ohms) 8 8 8
Frequency response (-6dB) 62Hz – 54kHz 55Hz – 54kHz 55Hz – 54kHz
Dispersion (degrees conical) 90 90 90
DRIVE UNITS
Dual Concentric™ high frequency 19mm (0.75”) Titanium dome 19mm (0.75”) Titanium dome 19mm (0.75”) Titanium dome
With Tulip WaveGuide
TM
With Tulip WaveGuide
TM
With Tulip WaveGuide
TM
Dual Concentric™ low frequency 100mm (4”) treated paper 100mm (4”) treated paper 100mm (4”) treated paper
pulp cone with pulp cone with pulp cone with
Rubber surround. Rubber surround. Rubber surround.
33mm (1.33”) edge 33mm (1.33”) edge 33mm (1.33”) edge
wound voice coil wound voice coil wound voice coil
Bass Driver - 100mm (4”) treated paper 100mm (4”) treated paper
- pulp cone with pulp cone with
- Rubber surround. Rubber surround.
- 33mm (1.33”) 33mm (1.33”)
- Wound voice coil Wound voice coil
Passive Radiator - - 100mm (4”) treated paper
pulp cone with
Rubber surround
CROSSOVER
Crossover frequency 1.5kHz 1.5kHz 1.5kHz
Crossover Type Passive low loss Passive low loss Passive low loss
2nd order LF, 1st order HF 2nd order LF, 1st order HF 2nd order LF, 1st order HF
CONSTRUCTION
Enclosure type Front ported Front ported Passive Radiator ported
Volume 4.2L (0.148 cu. ft.) 10.5L (0.37 cu. ft.) 7.7L (0.272 cu. ft.)
Dimensions (excl grille) H x W x D 270 x 169 x 175mm 850 x 169 x 175mm 169 x 448.5 x 175mm
(10.63 x 6.65 x 6.89”) (33.46 x 6.65 x 6.89”) (6.65 x 17.66 x 6.89”)
Weight
4.1kg (9.04lbs) 10.5kg (23.15lbs) 6.8kg (15.0lbs)
Finish Light oak and Espresso Light oak and Espresso Light oak and Espresso
010_ REVOLUTION SIGNATURE MANUAL
TECHNICAL SPECIFICATIONS
