06_ PRESTIGE GR & ST300-MG SUPERTWEETER MANUAL
TECHNICAL SPECIFICATIONS
PERFORMANCE
Recommended amplifier power Up to 350 Watts RMS
Continuous power handling
175 Watts RMS
700 Watts peak
Maximum sensitivity (2.83V @ 1m) 95 dB
Nominal impedance 8 Ohms
Frequency response (-6dB) 62 kHz, usable output (-18 dB) to 100 kHz
DRIVE UNITS
Driver type 25 mm diameter 44 micron magnesium alloy dome, with neodymium magnet system
CROSSOVER
Crossover type 3rd order high pass
Crossover frequency 14, 16 or 18 kHz adjustable
Level adjustment 89 dB, 90.5 dB, 92 dB, 93.5 dB, 95 dB
CONSTRUCTION
Dimensions (H x W x D) 130.4 x 146.9 x 206.2 mm (5.1 x 5.8 x 8.1”)
(incl. terminals)
FINISH
Prestige GR Walnut / Gold anodised machined aluminium
ST-300Mg Satin Black / Silver anodised machined aluminium
