Tannoy SuperTweeter Prestige GR ST-300Mg - Set Up Diagrams and Tables

PRESTIGE GR & ST300-MG SUPERTWEETER MANUAL_07
Mercury 7
SET-UP DIAGRAMS
Table 1
MODEL
10” Dual Concentric:
DISTANCE POSITION SENSITIVITY XOVER FREQ
LSU/HF/3LZL (Monitor Red)*,
LSU/HF/3LZG (Monitor Gold)*, HPD295*
Darking SL35, Windsor,
Ascot T125, Chester T165,
Dorset T185, Mayfair T225
73 mm A 90.5 dB 14 kHz
Buckingham 73 mm A 92.0 dB 14 kHz
System 10, System 1000 73 mm A 92.0 dB 16 kHz
D700 73 mm A 92.0 dB 18 kHz
3LZ, Chevening, Eaton, Caernarvon, SRM10B 100 mm D 90.5 dB 14 kHz
Stirling HW 100 mm D 92.0 dB 14 kHz
Stirling TW / TWW, Turnberry HE / SE 100 mm D 92.0 dB 16 kHz
Glenair 10 100 mm D 90.5 dB 16 kHz
Kensington / SE 100 mm D 93.5 dB 14 kHz
Definition DC10 / DC10i 73 mm A 92.0 dB 16 kHz
Definition DC10A 82 mm B 93.5 dB 18 kHz
Stirling HE / SE / GR 82 mm B 90.5dB 18 kHz
Turnberry LE / LE75 100 mm D 93.5 dB 16 kHz
Turnberry GR 100 mm D 92.0 dB 16 kHz
Kensington GR 100 mm D 93.5 dB 16 kHz
12” Dual Concentric:
LSU / HF / 12L (Monitor Silver)*,
LSU / HF / 12L (Monitor Red)*,
LSU / HF / 128G (Monitor Gold)*,
82 mm B 92.0 dB 14 kHz
HPD315* 82 mm B 90.5 dB 14 kHz
System 12, System 1200, D900 82 mm B 93.5 dB 16 kHz
Canterbury (corner), Lansdowne,
Chatsworth, Lancaster 12, DC4000, SGM1000
Edinburgh/ HW
SRM12B / X, SGM12B / X, LGM (Little Gold Monitor)
115 mm E 92.0 dB 14 kHz
Mansfield 12, Devon, Cheviot,
Bradley SL65, Chertsey SL45, Balmoral
Edinburgh / HW, Canterbury 12,
115 mm E 90.5 dB 14kHz
Edinburgh / TW / TWW / HE 115 mm E 93.5 dB 16 kHz
Yorkminster HE / SE 115 mm E 93.5 dB 14 kHz
