V15
Tannoy United Kingdom
Tannoy North America
Tannoy Deutschland
Tannoy France
T: 00 44 (0) 1236 420199
T: 00 1 (519) 745 1158
T: 00 49 (180) 1111 881
T: 00 33 (0)1 7036 7473
E: enquiries@tannoy.com
E: inquiries@tannoyna.com
E: anfragen@tannoy.com
E: ventes@tannoy.com
Tannoy adopts a policy of continuous improvement and product specification is subject to change
V15 data file // issue 1.04 // 18.03.08
TECHNICAL SPECIFICATIONS
System Type Full Range - Vented
Frequency Response (-3dB)
(1)
70Hz - 25kHz
Frequency Range (-10dB)
(1)
58Hz - 30kHz
System Sensitivity (1W @1m)
(2)
(1W = 2.83V for 8 Ohms)
Passive - Full Range: 100dB
Biamp (LF) 100dB
Biamp (HF) 107dB
Dispersion (-6dB) 75 degrees conical
Driver Complement 1 x 380mm (15.00”)
PowerDual™
Crossover Passive 1.4kHz
Product can be reconfigured for
bi-amped operation. Bi-amp system
parameters in user manual.
Directivity Factor (Q) 7.6 averaged 1kHz to 10kHz
Directivity Index (DI) 8.7 averaged 1kHz to 10kHz
Rated Maximum SPL
(2)
Average Peak
Passive - Full Range 126dB 132dB
Biamp (LF) 126dB 132dB
Biamp (HF) 125.5dB 131.5dB
Power Handling Average Programme Peak
Passive - Full Range 400W 800W 1600W
Biamp (LF) 400W 800W 1600W
Biamp (HF) 70W 140W 280W
Recommended Amplifier Power
Passive - Full Range 800W @ 8 Ohms
Biamp (LF) 800W @ 8 Ohms
Biamp (HF) 140W @ 8 Ohms
Nominal Impedance
Passive - Full Range 8 Ohms
Biamp (LF) 8 Ohms
Biamp (HF) 8 Ohms
10% Full Power (17.9V) 2nd Harmonic 3rd Harmonic
250Hz 1.0% 0.56%
1kHz 1.4% 1.0%
10kHz 3.9% 1.8%
1% Full Power (5.6V) 2nd Harmonic 3rd Harmonic
250Hz 0.31% 0.45%
1kHz 0.45% 0.79%
10kHz 3.16% 0.32%
Construction
Enclosure Vented and internally braced 63.5 litre,
15mm (0.62”) birch plywood enclosure
with 15mm (0.62”) MDF front baffle.
.
Finish Textured black or white paint
(Custom colours on request).
Foam covered, powder coated
perforated steel grille
Connectors 2 x Speakon NL4MP in/out
Fittings Recessed rear mounted carrying handle,
blanking plate covers recess for fitting of
35mm pole-mounting socket
8 x M10 bracket inserts allowing for
landscape or portrait mounting
8 x M10 flying inserts
Dimensions 590mm x 450mm x 420mm (H x W x D)
23.23” x 17.720” x 16.54” (H x W x D)
Weight 32kg (70.4lbs)
Notes:
(1) Average over stated bandwidth. Measured at 1 metre on axis.
(2) Unweighted pink noise input, measured at 1 metre in an anechoic chamber
A full range of measurements, performance data, CLF and Ease™ Data can be downloaded from
www.tannoy.com
Full independent verification of published specifications carried out by NWAA Labs, California can also be
obtained from the downloads section of www.tannoy.com
Tannoy operates a policy of continuous research and development. The introduction of new materials or
manufacturing methods will always equal or exceed the published specifications, which Tannoy reserves the
right to alter without prior notice. Please verify the latest specifications when dealing with critical applications.
System V15
Distortion
8001 2630 V15 Black 1
8001 2670 V15 White 1
PACKED QUANTITYCOLOURMODEL NAMEPART NUMBER
Ordering Information
