V300
Tannoy United Kingdom
Tannoy North America
Tannoy Deutschland
Tannoy France
T: 00 44 (0) 1236 420199
T: 00 1 (519) 745 1158
T: 00 49 (180) 1111 881
T: 00 33 (0)1 7036 7473
E: enquiries@tannoy.com
E: inquiries@tannoyna.com
E: anfragen@tannoy.com
E: ventes@tannoy.com
T
he loudspeaker shall consist of a 300mm (12.00”) full range, single point source SuperDual™ transducer. The low and the high frequency elements
s
hall be combined by an internal passive crossover network operating at 1.8kHz, with 2nd order high pass, 2nd order low pass. A configurable
s
witching arrangement on the input panel allows the user to select between full range passive or Bi-amped two way powering modes.
Performance of the loudspeaker, without any electronic control shall meet or exceed the following criteria: Frequency response measured at 1 metre
on axis with swept sine wave shall be 56Hz - 28kHz (-3dB). Sensitivity shall be at least 98dB (anechoic) for 2.83 Volts @ 1 metre and shall be
capable of producing a peak output level of 128dB (anechoic) on axis at 1 metre.
The dispersion of the loudspeaker shall be 90 degrees conical (-6dB). The system shall have a nominal impedance of 8 Ohms, maximum power handling
shall be 500 Watts (programme). The enclosure shall be an optimally tuned (44.5 litre), vented and internally braced enclosure of birch plywood construction.
The enclosure shall be fitted with a recessed rear mounted carrying handle, 8 x M10 bracket inserts and 8 x M10 integral mounting points for flying hardware.
T
he enclosure shall not exceed the following dimensions: 590 x 370 x 375mm (H x W x D) 23.23 x 14.57 x 14.76“ (H x W x D)
The loudspeaker shall be the Tannoy...V300.
Architectural specifications
Tannoy adopts a policy of continuous improvement and product specification is subject to change
