V300
Tannoy United Kingdom
Tannoy North America
Tannoy Deutschland
Tannoy France
T: 00 44 (0) 1236 420199
T: 00 1 (519) 745 1158
T: 00 49 (180) 1111 881
T: 00 33 (0)1 7036 7473
E: enquiries@tannoy.com
E: inquiries@tannoyna.com
E: anfragen@tannoy.com
E: ventes@tannoy.com
Tannoy adopts a policy of continuous improvement and product specification is subject to change
V300 data file // issue 1.06 // 15.01.08
TECHNICAL SPECIFICATIONS
1
0% Full Power (14.14V) 2nd
H
armonic
3
rd
H
armonic
250Hz 0.63% 0.08%
1
kHz 0.92% 0.20%
10kHz 1.45% 0.17%
1
% Full Power (4.47V) 2nd
H
armonic
3
rd
H
armonic
250Hz 0.32% 0.02%
1kHz 0.28% 0.02%
1
0kHz 0.41% 0.08%
Construction
Enclosure 44.5 litre vented and internall braced
15mm (0.62”) birch plywood cabinet
with 15mm (0.62”) MDF front baffle.
Finish Textured black or white paint, with
custom colours on request.
Foam covered, powder coated
p
erforated steelgrille
Connectors 2 x Speakon NL4MP in/out
Optional Accessories Black or white power coated perforated
steel grille
Fittings Recessed rear mounted carry handle
Blanking plate allows installation
of a 35mm pole-mounting socket
8 x M10 bracket inserts allowing for
landscape or portrait mounting
8 x M10 flying inserts
Dimensions 590mm x 370mm x 375mm (H x W x D)
23.23 x 14.57 x 14.76” (H x W x D)
Weight 34 Kg (74.8 lbs)
Notes:
(1) Average over stated bandwidth. Measured at 1 metre on axis.
(2) Unweighted pink noise input, measured at 1 metre in an anechoic chamber
A full range of measurements, performance data, CLF and Ease™ Data can be downloaded from
www.tannoy.com
Full independent verification of published specifications carried out by NWAA Labs, California can also be
obtained from the downloads section of www.tannoy.com
Tannoy operates a policy of continuous research and development. The introduction of new materials or
manufacturing methods will always equal or exceed the published specifications, which Tannoy reserves the
right to alter without prior notice. Please verify the latest specifications when dealing with critical applications.
System V
300
System V300
S
ystem Type Full Range - Vented
F
requency Response (-3dB)
(1)
7
0Hz - 22kHz
Frequency Range (-10dB)
(1)
56Hz - 28kHz
System Sensitivity (1W @1m)
(2)
98dB (1W = 2.83V for 8 Ohms)
Dispersion (-6dB) 90 degrees conical
Driver Complement 1 x 300mm (12.00”) constant
directivity Super Dual™
Crossover Passive 1.8kHz
Product can be reconfigured
for bi-amped operation.
Bi-amp system parameters
in user manual
Directivity Factor (Q) 7.4 averaged 1kHz to 10kHz
Directivity Index (DI) 8.4 averaged 1kHz to 10kHz
Rated Maximum SPL
(2)
Average Peak
Passive - Full Range 122dB 128dB
Biamp (LF) 122dB 128dB
Biamp (HF) 122.5dB 128.5dB
Power Handling
Average Programme Peak
Passive - Full Range 250W 500W 1000W
Biamp (LF) 250W 500W 1000W
Biamp (HF) 70W 140W 280W
Recommended Amplifier Power
Passive - Full Range 500W @ 8 Ohms
Biamp (LF) 500W @ 8 Ohms
Biamp (HF) 140W @ 8 Ohms
Nominal Impedance
Passive - Full Range 8 Ohms
Biamp (LF) 8 Ohms
Biamp (HF) 8 Ohms
8001 2640 V300 Black 1
8001 2680 V300 White 1
PACKED QUANTITYCOLOURMODEL NAMEPART NUMBER
Ordering Information
