13.3 Biamp System Parameters
Parameter Unit/Name Low Section High Section
Gain (dB) 0 -6
Delay (ms) 0 0
Polarity Positive Positive
HPF â Freq (Hz) 45.1 1920
Slope (dB/oct) 24 24
Filter Shape Butterworth Linkwitz Riley
LPF Freq (Hz) 1820 Thru
Slope (dB/oct) 24 NA
Filter Shape Linkwitz Riley NA
Freq (Hz) 60.1 6100
Level (dB) +7 +3.5
Type Parametric Hi - Shelf
PEQ 1 ââ
Q / Bandwidth 2.8 / 0.3536 NA
Freq (Hz) 281 10500
Level (dB) -2.5 +4
Type Parametric Parametric
PEQ 2
Q / Bandwidth 2 / 0.500 9.5 / 0.1051
Freq (Hz) 749 NA
Level (dB) -2 NA
Type Parametric NA
PEQ 3
Q / Bandwidth 2 / 0.500 NA
Freq (Hz) 606 NA
Level (dB) -2 NA
Type Parametric NA
PEQ 4
Q / Bandwidth 6 / 1.669 NA
Freq (Hz) 1650 NA
Level (dB) -2 NA
Type Parametric NA
PEQ 5
Q / Bandwidth 7.1 / 0.1403 NA
ââ Note : When using the V300 with subs, set HPF on LF section @ 80 – 100Hz
(24dB/oct LR) and omit PEQ1 (on LF only)
PEQ 1 (on LF only) may also be omitted when using the V300 as a floor monitor.
