Mounting and xing
Wall Bracket
Each VLS Series loudspeaker is supplied with a standard wall bracket suitable for mounting on most wall surfaces. The bracket is supplied as two interlocking U plates.
One plate attaches to the rear of the loudspeaker with four supplied screws. The other part is secured to the wall. The bar on the bottom of the speaker plate slides
into the bottom notch of the wall plate, while the top is secured with the two supplied screws. The bracket for the VLS 7 (EN 54) and VLS 15 (EN 54) is slotted to allow
an angle between 0 and 6 degrees (Fig.3). Aligning the top two screw holes of the VLS 30 results in a at ush mount; using the lower two screw positions provides a
4 degree downwardtilt. (Fig.4)
Pan-Tilt Bracket (optional)
A pan-tilt bracket is available which allows panning and tilting for exible orientation along both horizontal and vertical axes. Installation instructions are provided
with the bracket.
Rigging and safety procedures
The installation of Tannoy loudspeakers using the dedicated hardware should be carried out only by fully quali ed installers, in accordance with all the required safety
codes and standards that are applied at the place of installation.
WARNING: As the legal requirements for ying vary from country to country, please consult your local safety standards o ce before installing any product.
We also recommend that you thoroughly check any laws and bylaws prior to installation. For more detailed information on rigging hardware and safety procedures,
please consult the full VLS Series Operation Manual.
Outdoor applications
VLS Series loudspeakers are rated IP64 for resistance to dust and moisture ingress, and are resistant to both salt spray and UV exposure, making them suitable for use
in most outdoor applications. Please consult with your Tannoy dealer before installation in applications with extreme exposure to adverse environmental conditions
such as prolonged heavy rainfall, prolonged temperature extremes, etc.
IMPORTANT NOTE: The mounting of a permanently installed sound system may be dangerous unless undertaken by quali ed personnel with the required experience
and certi cation to perform the necessary tasks. Walls, oors or ceilings must be capable of safely and securely supporting the actual load. The mounting accessory
used must be safely and securely xed both to the loudspeaker and to the wall, oor or ceiling.
When mounting rigging components on walls, oors or ceilings, ensure that all xings and fasteners used are of an appropriate size and load rating. Wall and ceiling
claddings, and the construction and composition of walls and ceilings, all need to be taken into account when determining whether a particular xing arrangement
can be safely employed for a particular load. Cavity plugs or other specialist xings, if required, must be of an appropriate type, and must be tted and used in
accordance with the maker’s instructions.
The operation of your speaker cabinet as part of a own system, if installed incorrectly and improperly, can potentially expose persons to serious health risks and
even death. In addition, please ensure that electrical, mechanical and acoustic considerations are discussed with quali ed and certi ed (by local state or national
authorities) personnel prior to any installation or ying.
Make sure that speaker cabinets are set up and own by quali ed and certi ed personnel only, using dedicated equipment and original parts and components
delivered with the unit. If any parts or components are missing please contact your Dealer before attempting to set up the system.
Be sure to observe the local, state and other safety regulations applicable in your country. Music Group, including the Music Group companies listed on the
enclosed “Service Information Sheet”, assumes no liability for any damage or personal injury resulting from improper use, installation or operation of the product.
Regular checks must be conducted by quali ed personnel to ensure that the system remains in a secure and stable condition. Make sure that, where the speaker is
own, the area underneath the speaker is free of human tra c. Do not y the speaker in areas that can be entered or used by members of the public.
Speakers create a magnetic eld, even if not in operation. Therefore, please keep all materials that can be a ected by such elds (discs, computers, monitors, etc)
at a safe distance. A safe distance is usually between 1 and 2 metres.
