Tannoy VLS SERIES User Manual

10. Technical specifications
VLS Series Operation Manual rev 1.0.0
13
10. Technical specifications
Peformance
Frequency Response (-3 dB)
1)
150 Hz - 11 kHz 150 Hz - 30 kHz 120 Hz - 22 kHz
Frequency Range (-10 dB)
1)
110 Hz - 14 kHz 110 Hz - 35 kHz 90 Hz - 35 kHz
System Sensitivity (1 W @1 m)
2)
90dB 91dB 94dB
Horizontal dispersion (-6 dB)
130 degrees horizontal 130 degrees horizontal 130 degrees horizontal
Vertical dispersion (-6 dB)
+6degrees/-22degrees +6degrees/-22degrees +3/-11degreesVertical
(-8 degree bias) (-8 degree bias) (-4 degrees bias)
Driver complement
7x3.5”(89mm)fullrangedrivers 7x3.5”(89mm)woofers 14x3.5”(89mm)woofers
8x1”(25mm)metaldometweeters 16x1”(25mm)metaldometweeters
Crossover
Passive network utilising Passive network utilising Passive network utilising
FocussedAsymmetricalShaping FocussedAsymmetricalShaping FocussedAsymmetricalShaping
Technology(FAST) Technology(FAST) Technology(FAST)
Directivity factor (Q)
6.1 averaged 1 kHz to 10 kHz 9.1 averaged 1 kHz to 10 kHz 15 averaged 1 kHz to 10 kHz
Directivity index (DI)
7.9 averaged 1 kHz to 10 kHz 9.6 averaged 1 kHz to 10 kHz 11.8 averaged 1 kHz to 10 kHz
Rated maximum SPL
2)
112dB(average),118dB(peak) 114dB(average),120dB(peak) 120dB(average),126dB(peak)
Power handling
150 W (average), 200 W (average), 400 W (average),
300 W (programme), 400 W (programme), 800 W (programme),
600 W (peak) 800 W (peak) 1600 W (peak)
Recommended Amplier Power
450 W @ 8 ohms 600 W @ 8 ohms 1200 W @ 4 ohms
Nominal Impedance
12 ohms 12 ohms 6 ohms
Construction
Enclosure
Aluminiumextrusion Aluminiumextrusion Aluminiumextrusion
Finish
Ral 9003 (white) Ral 9003 (white) Ral 9003 (white)
& Ral 9004 (black) & Ral 9004 (black) & Ral 9004 (black)
CustomRALnishesavailable CustomRALnishesavailable CustomRALnishesavailable
(additional cost and lead-time) (additional cost and lead-time) (additional cost and lead-time)
Connectors
Barrierstrip Barrierstrip Barrierstrip
Fittings
Flying bracket, wall mount bracket, Flying bracket, wall mount bracket, Flying bracket, wall mount bracket,
input panel cover plate and gland input panel cover plate and gland input panel cover plate and gland
Physical
Dimensions
W:121mm(4.8”) W:121mm(4.8”) W:121mm(4.8”)
H:816.5mm(32.1”) H:816.5mm(32.1”) H:1460.5(57.5”)
D: 146 mm (5.7’) D: 146 mm (5.7’) D: 146 mm (5.7’)
Packed quantity
1 1 1
Net weight
10.4 kg (22.9 lbs) 11.3 kg (24.9 lbs) 20 kg (44 lbs)
Shipped weight
13 kg (28.7 lbs) 14 kg (30.9 lbs) 23 kg (50.7 lbs)
(1)Averageoverstatedbandwidth.Measuredat1metreon-axis.
(2) Unweighted pink noise input,measured at 1 metre in an anechoic chamber
Afullrangeofmeasurementsandperformancedatacanbedownloadedfromwww.tannoy.com.Forproject-specicsystemdesignassistance,contactourApplicationsEngineeringand
Training (AET) group via www.aetgroup.tc
Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods may introduce variances; however, performance will
alwaysequalorexceedthepublishedspecications.Allspecicationsaresubjecttochangewithoutnotice.FASTisatrademarkofTannoyLimited.Allothertrademarksremainthe
property of their respective owners.
VLS 7 VLS 15 VLS 30
