TapFlo TX120 - T820 - Spare Parts List

5. SPARE PARTS
IOM manual Tapflo Metal Series 45
5.2.7. T820 – Spare parts list
Pos.
Q-ty
Description
Material
KIT
LIQ
KIT
AIR
11
2
Housing
AISI 316L
12
1
Centre block
PP
131
1
Manifold inlet
AISI 316L
132
1
Manifold outlet
AISI 316L
14
8
Pin screw
A4-80
141
32
Hexagon bolt
A4-70
15
2
Diaphragm
EPDM, PTFE, NBR
X
16
1
Diaphragm shaft
AISI 316L
X
17
1
Stand
AISI 304
174
2
Hexagon fit bolt
AISI 316L
175
2
Washer
A2-70
176
2
Hexagon socket head cap screw
A2-70
1791
2
Lifting eye bolt
A2-70
1792
2
Washer
A4
18
4
Flat gasket
EPDM, PTFE
X
X
181
4
O-ring
FEP FKM
X
X
222
4
Valve seat
AISI 316L
227
16
Leading screw
AISI 316L
23
4
Valve ball
PTFE, EPDM, NBR, PU
X
25
1
Muffler
PP
X
26
1
Air intake adapter
Brass
27
2
Circlip
Cr3 coated steel
30
6
O-ring
NBR, FKM, EPDM
36
4
Centre block seal
PE
X
37
16
Cap nut
A4-70
371
32
Hex nut
A4-70
38
16
Spring washer
A4-80
381
32
Spring washer
A4-70
47
4
O-ring (back up for 36)
NBR
X
61
1
Air valve complete
Body: PET (std.), brass, AISI316L
O-rings: NBR (std.), FKM, EPDM
X
90*
1
Grounding set
AISI 316L
*= On ATEX pumps
