Slope Flail Mowers BCRL & BCRM
Operating Instructions
Belt tension adjustment
It is necessary to adjust the belt tension as the belts stretch. Correct belt tensioning ensures that
the machine works properly.
To adjust the belts tension:
• Remove the belt shield.
• Loosen (do not remove hardware holding the gearbox support in place).
• Tighten belts by turning the nut on the belt adjustment plate.
• Retighten the gearbox support hardware.
Remove belt shield Adjustment nut
