DRL-048, DRL-072 Crop Seeder
Assembly
Step 3:
Separate the hoses which come with the machine. The
5 longer hoses are to be installed from the front seed
cups to the rear double disc openers. The longer hoses
are darkened in the illustration for clarity.
Step 4:
Use clamps to secure the hoses to the seed cups.
Step 5:
Insert the shut off flaps into each of the seed cups.
