19
ERC Square Back Rotary Cutter
Maintenance/Service
Lubrication
Every 8 hours:
Grease the tail wheel yoke and the tail wheel hub, Fig. 5A.
Check the gear box oil by observing the site glass on the LH side of the gearbox. Add SAE 90W gear oil as
needed, Fig. 5A.
Grease the PTO shaft and apply a light layer of grease on the inner tube, Fig. 5B.
Grease
Oil
Fig. 5A
Fig. 5B
Grease
Grease
Coat PTO inner tube with a thin layer of grease
