Targa Visionary LCD 22-1 Wide
11
English
Button Function Overview
You can use the control buttons to access the most common
settings directly.
Setting Brightness and Contrast
1. Press the
(12) or (13) buttons. The brightness and
contrast menu will appear.
2. Press the
(12) or (13) buttons to select a menu option
(Brightness will be disabled while DCR is on).
3. Press button 2 (14) to enable the selected menu item.
4. Press the (12) or (13) buttons to select the desired
value.
5. Wait until the menu disappears or press button 1 (11) twice
to exit the menu immediately.
DCR means „Dynamic Contrast Ratio“ and offers an
optimum contrast by adjusting the display backlight
automatically depending on the picture contents.
Auto Image Adjust
Automatically adjusts the settings for the horizontal and vertical
position, the horizontal size as well as the fine control and
sharpness.
To do this, press button 2.
