Diagram 4 – Handle Group, 11 hp Honda Gas

Diagram 4 Parts List – Handle Group, 11 hp Honda Gas

ITEM P/N DESCRIPTION QTY

1 ------ Handle Assembly, Target Gas 1

2 177786 Adjustable Handle Weldment 1

3 139568 Grip, Handle 2

4 177836 Choke Cable Modified 1

5 177797 Cable Assembly, Engine Throttle Modified 1

6 167761 Capscrew, Hex Hd M5 x 0.8 x 20mm 2

7 173047 Washer, Flat M4 2

8 172316 Locknut, Fiber M5 x 0.8 2
