Target Made By Design Horizontal Bookcase - Table of Contents

4
support foot
(H12) x 2
L-bracket
(H12) x 3
63/64” flat-head screw
(H13) x 2
conformat screw
(H1) x 4
large cam
(H2) x 2
small cam
(H3) x 8
cam cover cap
(H5) x 2
short cam bolt
(H4) x 4
long cam bolt
(H6) x 2
knob
(H7) x 4
large wooden dowel
(H8) x 2
small wooden dowel
(H10) x 1
allen wrench
(H9) x 1
glue
(H11) x 4
L-bracket
(H12) x 2
hinge
(H13) x 16
1/2” pan-head screw
(H15) x 2
7/8” pan-head machine screw
(H14) x 8
Glue
(H16) x 4
2” hex-head screw
(H17) x 4 (H18) x 12
1-1/8” washer-head screw
(H20) x 1
touch-up stick
(H19) x 35
nail
(H21) x 2 sets
drawer glides
(H22) x 1
magnetic catch
(H23) x 1
strike plate
(H25) x 1
strike plate screw
(H24) x 2
magnetic catch screw
(H10) x 1
allen key
(H11) x 3
staple
(H1) x 10
large cam
(H5) x 8 (H6) x 2
wedgefix dowel
(H3) x 12
wooden dowel
(H4) x 8
wedgefix housing
(H7) x 4
support foot
(H8) x 40
nails
(H9) x 1
nail guide
(H2) x 10
metal dowel
(H15) x 4
spacer
(H14) x 2
L-bracket
3/8” flat-head screw
(H17) x 2 (H18) x 2
2”3/8 screw TC
(H16) x 2
plastic wall plug
table of contents
introduction 2-3
hardware 5
parts list 6
how to use the cam lock system 7
assembly 8-25
QUESTIONS? Just call 855-MYTGTHOME (1-800-440-0680) for parts and service. For faster service, have the DPCI number ready when calling.
