Tascam 133-B - Page 2

Equalization:
Frequency Response 2):
(Record/Reproduce)
0 VU
-20 VU
Total Harmonic Distortion3):
Signal to Noise Ratio3):
(Ata reference of 3%
distortion level)
Adjacent Channel Separation:
Cross Talk Audio to Cue Track:
Erasure:
Headroom
Recording Amplifier:
Reproduce Amplifier:
(tl) Cue Track:
Line Input
Input Impedance:
Nominal Input Level:
Minimum {nput Level:
Line Output
Minimum Load Impedance:
Nominal Load Impedance:
Nominal Output Level:
Maximum Output Level:
Standard Recording Level:
Equalization:
Frequency Response: 3) ~3 dB*
(Record/Reproduce)
-23 dB*
Total Harmonic Distortion: 2)
Signal to Noise Ratio: 2)
(Ata reference of 3 %
distortion level)
Cross Talk Cue to Audio Tracks:
Cue Tone Generator:
Erasure:
Headroom
Recording Amplifier:
Reproduce Amplifier:
(111) Power Requirement:
* signifies peak meter values.
| 133-B
1-7/8 ips (4.76 cm/s) 3180 ps + 70 us
3-3/4 ips (9.5 cm/s) 3180 ps + 35 ys
1-7/8 ips (4.76 cm/s) 30 — 8 kHz +3 dB
3-3/4 ips (9.5 cm/s) 30 — 15 kHz +3 dB
1-7/8 ips (4.76 cm/s) 30 — 12.5 kHz +3 dB
3-3/4 ips (9.5 cm/s) 30 — 15 kHz +3 dB
1.5 % atO VU, 1 kHz, 160 nWb/m
1-7/8 ips (4.76 cm/s) 3 % at 5: dB above 0 VU, 1 kHz, 285 nWb/m
3-3/4 ips (9.5 cm/s) 3% at 5 dB above 0 VU, 1 kHz, 285 nWb/m
1-7/8 ips (4.76 cm/s) 55 dB weighted
50 dB unweighted
3-3/4 ips (9.5 cm/s) 55 dB weighted
: 50 dB unweighted
Better than 45 dB at 1 kHz
Better than 55 dB at 1 kHz
Better than 65 dB at 1 kHz, +10 dB above 0 VU
Better than +17 dB above 0 VU
Better than +17 dB above 0 VU
70k ohms, unbalanced
-10 dBV (0.3 V)
~20 dBV (0.1 V)
‘10k ohms
50k ohms
-7 dBV (0.4 V)/+3 dBV (1.4 V), switchable
—4.dBV.{0.9 V)/+9 dBV (2.8 V), switchable
200 nWb/m=0 dB*
1-7/8 ips (4.76 cm/s) 3180 ps + 70 us
3-3/4 ips (9.5 cm/s} 3180 ps + 35 ps
1-7/8 ips (4.76 cm/s) 30 — 8 kHz +3 dB
3-3/4 ips (9.5 cm/s) 30 — 12.5 kHz +3 dB
1-778 ips (4:76 cm/s) 30 — 10 kHz +3 dB
3-3/4 ips (9.5 cm/s) 30 — 12.5 kHz +3 dB
2.0 % at -3 dB*, 1 kHz, 160 nWb/m
1-7/8 ips (4.76 cm/s) 3 % at 5 dB above -3 dB”, 1 kHz, 285 nWb/m
3-3/4 ips (9.5 cm/s) 3% at 5 dB above -3 dB*, 1 kHz, 285 nWb/m
1-7/8 ips (4.76 cm/s) 55 dB weighted
50 dB unweighted
3-3/4 ips (9.5 cm/s) 55 dB weighted
50 dB unweighted
Better-than 55 dB at 1 kHz
25 Hz, 1 sec.
Better than 65 dB at 1 kHz, +10 dB reference
Better than +17 dB above: -3 dB*
Better than+17-dB above -3 dB”
100/120/220/240 V AC, 50/60 Hz, 57 W
(General Export Model)
120 V AC, 60 Hz, 57 W
(USA/Candda Model)
220 V AC, 50 Hz, 57 W
(Europe Model)
240 V AC, 50 Hz, 57 W
(UK/AUS Model)
In these specifications, 0 dBV is referenced to 1.0 Volt. Actual voltage levels also are given in parenthesis. To
calculate the 0 dB = 0.775 Volt reference level (i.e., 0 dBm in a 600-ohm circuit) add 2.2 dB to the listed
dB value;i.e., -10 dB re: 1 V = -7.8 dB re:0.775 V.
@ 1) Specifications were determined using TEAC Test Tape MTT-111.
2) Specifications were determined using TEAC Test Tape MXT-111.
3) Specifications were determined using TEAC Test Tape MTT-5061.
Dolby level is referenced to +3 VU.
Changes in specifications and features may be made without notice or obligation.
