©Copyright Task Force Tips, Inc. 2002-2015 LIX-630 July 2, 2015 Rev19
17
INDEX DESCRIPTION QTY ITEM #
1 GASKET 2.5" 1 V3190
2 1/4-28 X 1/2 SOCKET SET SCREW 1 VT25-28SS500
3 3/16" SS BALL 48 V2120
4 COUPLING 2.5" 1 M307*
5 INLET SWIVEL 1 XX605
6 O-RING-235 1 VO-235
7
COVER PLATE 1 XX205
COVER PLATE GASKET 1 XX200
8 10-24 1/2 BUTTON HEAD SCREW 4 VT10-24BH500
9 INSTRUCTION LABEL 1 XL670
10 10-24 X 1/4 SOCKET SET SCREW 1 VT10-24SS250
11 QUAD-RING-231 1 VOQ-4231
12 DRAG DISK 1 XX645
13 O-RING-109 2 VO-109
14 DISC RETAINER 4 XX642
15 WASHER 4 VW687X281-50
16 1/4-28 X 1/2 BUTTON HEAD SCREW 6 VT25-28BH500
17 1/4-20 X 1 BUTTON HEAD SCREW 2 VT25-20BH1.0
18 LEFT HANDLE 1 XX621
19 3/8-16 X 1-1/2 BUTTON HEAD SCREW 2 VT37-16BH1.5
20 HANDLE LABEL 2 XL620
21 LEFT LEG 1 XX470L
22
BODY 1 XX600
TRIP MECHANISM 1 XX910
23 SWIVEL TRUNNION 2 XX320
24 SQUARE BUSHING 1 XX630
25 CAM PIN 1 XX610
26 O-RING-230 TEFLON 1 VO-230T
27 DISK 1 XX640
28 3/8-16 X 1.7 BUTTON HEAD SCREW 1 VT37-16BH1.7
29 PULL PIN 1 XX343
INDEX DESCRIPTION QTY ITEM #
30 PULL PIN SPRING 1 XX342
31 PULL PIN HOUSING 1 XX355
32 PULL KNOB 1 XX341
33 1/8 X 3/4 HDP SPIROL PIN 1 VP125X750H
34 HANDLE TOP 1 XX625
35 RIGHT HANDLE 1 XX620
36 DETENT SPRING 4 XX655
37 3/8" TORLON BALL 4 VB375TO
38 LEG RETAINER 2 XX475
39 LEG RETAINER PIN 2 XX476
40 1/4-20 X 1 SOCKET HEAD SCREW 4 VT25-20SH1.0
41 RIGHT LEG 1 XX470R
42 REAR SPIKE 2 X482
43 O-RING-227 2 VO-227
44 SLIDER 1 XX660
45 VALVE PLUG 1 XX590
46 3/8-24 X 1-3/4 SOCKET HEAD SCREW 1 VT37-24SH175
47 PLUG SUPPORT 1 XX594
48 LOCKING SLEEVE 1 XX571
49 O-RING-241 1 VO-241
50 WAVE SPRING WASHER 2 VW740X550-16
51 5/16-18 X 1/4 SOCKET SET SCREW 2 VT31-18SS250
52 EXIT 2.5" 1 XX310*
53 O-RING-146 1 VO-146
54 STREAM STRAIGHTENER INSERT 1 V4040
A BLITZFIRE OUTLET 1
SEE SECTION
10.3
B HIGH ELEVATION BLITZFIRE OUTLET 1
SEE SECTION
10.4
C HIGH ELEVATION BLITZFIRE OSCILLATOR 1
SEE SECTION
10.5
* - CONSULT FACTORY FOR SPECIAL THREADS
10.2.1 BLITZFIRE MONITOR PARTS LIST
