Task Force Tips EDUCTOR 125 Series Instructions For Installation, Operation And Maintenance

©Copyright Task Force Tips LLC 2010-2021 7 LIU-330 February 15, 2021 Rev09
5.3 FOAM CONSUMPTION
The following tables indicate the theoretical foam concentrate flow rate and the time it will take to empty a 5 gallon (18.9 liters) container
of various concentrates with eductors of different ratings.
TESTING NOTES:
1. The Class A foam used for calibration is the “Knock Down” from National Foam. The calibration viscosity is 20 Centipoise.
2. The class B foam used for calibration is the “Universal Plus 3%/6% Alcohol Resistant Aqueous Film Forming Foam” (AR-AFFF)
from National Foam. The calibration viscosity is 2892 Centipoise tested with Brookfield #3 Spindle @ 30 rpm.
3. TFT’s eductors were calibrated with 1 ¾” Conquest Hose.
- UE-060-NF calibration hose length is 300 ft.
- UE-095-NF calibration hose length is 250 ft.
- UE-125-NF calibration hose length is 150 ft.
60 GPM (225 L/min) Eductor 95 GPM (360 L/min) Eductor
Setting Foam
Class
Time to Empty
5 Gallons
Foam Flow
Rate
Setting Foam
Class
Time to Empty
5 Gallons
Foam Flow
Rate
1/4% A 33 min 20 sec 0.15 gpm
(.057 L/min)
1/4% A 20 min 50 sec 0.24 gpm
(0.9 L/min)
1/2% A 16 min 40 sec 0.3 gpm
(1.14 L/min)
1/2% A 10 min 25 sec 0.5 gpm
(1.89 L/min)
1% B 8 min 20 sec 0.6 gpm
(2.27 L/min)
1% B 5 min 16 sec 1.0 gpm
(3.78 L/min)
3% B 2 min 47 sec 1.8 gpm
(6.81 L/min)
3% B 1 min 45 sec 2.9 gpm
(10.97 L/min)
6% B 1 min 23 sec 3.6 gpm
(13.62 L/min)
6% B 53 sec 5.7 gpm
(28.38 L/min)
120 GPM (450 L/min) Eductor 125 GPM (475 L/min) Eductor
Setting Foam
Class
Time to Empty
5 Gallons
Foam Flow
Rate
Setting Foam
Class
Time to Empty
5 Gallons
Foam Flow
Rate
1/4% A 16 min 40 sec 0.29 gpm
(1.09 L/min)
1/4% A 16 min 0.3 gpm
(1.14 L/min)
1/2% A 8 min 20 sec 0.58 gpm
(2.18 L/min)
1/2% A 8 min 0.6 gpm
(2.27 L/min)
1% B 4 min 10 sec 1.25 gpm
(4.72 L/min)
1% B 4 min 1.3 gpm
(4.92 L/min)
3% B 1 min 23 sec 3.65 min
(13.8 L/min)
3% B 1 min 20 sec 3.8 gpm
(14.38 L/min)
6% B 42 sec 7.2 gpm
(27.25 L/min)
6% B 40 sec 7.5 gpm
(28.38 L/min)
Actual calibrated rate for each setting and
the foam concentration used for calibration
Setting Actual
Rate
Foam
Class
UL-162
Tolerance
1/4% 0.287% A .25 - .325%
1/2% 0.575% A .5 - .65%
1% 1.15% B 1 - 1.3%
3% 3.45% B 3 - 3.9%
6% 6.5% B 6 - 7%
