10.0 DRAWINGS AND PARTS LIST
1
11
3
3
37
38
39
4
4
5
6
7
8
9
11
10
11
12
13
14
16
17
18
15
20
21
23
22
24
19
1
11
25
29
30
26
27
31
32
33
34
28
28
36
35
28
#
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
QTY
2
21
1
1
1
1
1
1
1
4
1
1
1
1
1
1
1
3
1
1
1
DESCRIPTION
Pull Pin
3/16 SS Balls
1/4-28 x 1/2 Set Screw
1.0 Hose Gasket
1.0 Coupling*
1.5 Hose Gasket
Angled Swivel
Quad Seal
Rear Block
Circle Cotter
024 O-Ring
Handle
Flow Label
022 O-Ring
Handle Plug
Valve
Valve Pointer Label
124 O-Ring
1/4-20x3/4 Stud
Knob Nut
Knob Spring
PART #
U180
V2120
VT25-28SS500
V3040
U260*
V3030
U265
VOQ-4316
U270
U182
VO-024
U240
UL500
VO-022
U241
U250
UL504
VO-124
U223
U221
U222
#
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
QTY
1
1
1
1
1
4
1
1
1
1
1
1
1
2
1
1
34
DESCRIPTION
Percent Knob Label
Percentage Knob
Vinyl Cap
Spirol Pin
Rear Venturi Insert
Dog Point Screw
120 O-Ring
Venturi Cap
Cable Assembly
Cup Seal
Front Venturi Insert
Control Block
Foam Pick Up Tube
Follower
1.5 Coupling *
Port Plug
3/16 SS Balls
PART #
UL505
U230
VM1030
V1900
U214
H515
VO-120
U213
VM1020
U212
U210
U200
U202
U251
F10010*
B770
V2120
* Specify Coupling Type
WATERWAY SUBASSEMBLY
PART #U800
